Tucson FWD V6-27L (2009) Towing System Service and Repair
Towing Information: Service and Repair
Towing
If the vehicle needs to be towed, call a professional towing service. Never tow vehicle with just a rope or chain. It is very dangerous.
If the vehicle cannot be transported by flat-bed, if should be towed with the front wheels off the ground. If due to damage, the vehicle must be toward
with the front wheels on the ground, do not following :
Manual Transmission
-
Release the parking brake.
-
Shift the transmission to neutral
Automatic Transmission
-
Release the parking brake.
-
Start the engine.
-
Shift to [D] position, then [N] position.
-
Turn off the engine.
CAUTION:
-
Improper towing preparation will damage the transmission. Follow the above procedure exactly. If you cannot shift the transmission or start
the engine(automatic transmission), your vehicle must be transported on a flat bed.
-
It is the best to tow vehicle no farther than 19miles (30km), and keep the speed below 30mph (50km/h).
-
Trying to lift or tow your vehicle by the bumpers will cause serious damage. The bumpers are not designed to support the vehicle's weight.
Front :
Rear :
