Veracruz AWD V6-3.8L (2007)
Antitheft Antenna: Service and Repair
COIL ANTENNA
REMOVAL
1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel (A).
3. Disconnect the 6P connector of the coil antenna and then remove the coil antenna (A) after loosening the screw.
INSTALLATION
1. Reassemble the coil antenna after connecting the connector.
2. Reassemble the crash pad lower panel.
