G37 Convertible V6-3.7L (VQ37VHR) (2010)
/Page-1128001.png)
Power Distribution Module: Initial Inspection and Diagnostic Overview
Work Flow
DIAGNOSIS AND REPAIR WORK FLOW
Work Flow
OVERALL SEQUENCE
DETAILED FLOW
1.GET INFORMATION ABOUT SYMPTOM
Get detailed information from the customer about the symptom (the condition and the environment when the incident/malfunction occurs).
- GO TO 2.
2.CHECK DTC
1. Check DTC for BCM and IPDM E/R.
