J30t V6-2960cc 3.0L DOHC MFI (VG30DE) (1997)
Technical Service Bulletin # 00-002
Date: 991215
Sunroof Rail Assembly Repair
Reference:
ITB00-002
Classification:
BT99-050
Date:
December 15, 1999
SUNROOF RAIL ASSEMBLY REPAIR
APPLIED VEHICLES: 1996-97 I30 (CA32)
1997-99 QX4 (JR50)
1997-98 Q45 (FY33)
1993-97 J30 (JY32)
PARTS INFORMATION
CLAIMS INFORMATION
NOTE: This is the ONLY approved repair procedure for this incident. A claim to Infiniti for the repair of this incident may be denied if the repair is not
performed exactly as outlined in this bulletin.
Submit a Primary Failed Part (PP) line using the following claims coding;
* Reference the Parts Information table and use the indicated "Sunroof Repair Kit" P/N as the PFP.
Service Information
SERVICE INFORMATION
If an applied vehicle exhibits the following symptoms, use the service procedure below to resolve the incident(s).
-
Sunroof binds
-
Sunroof motor runs but the sunroof will not open or close
-
Sunroof leaks
