Bose Surround Audio 5.1CH System

FRONT DISPLAY UNIT

Wiring Diagram - AV - / BOSE Surround Audio 5.1ch System

NOTE:
The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION
SWITCH virtually.
