X-Type (X400) V6-3.0L (2002)

Page 1
background image

Vacuum Pump: Service and Repair

Brake Vacuum Pump

Removal

1. Disconnect the vacuum hose.

^

Release the retaining clip.

2. Disconnect the electrical connector.
