X-Type (X400) V6-3.0L (2002)

Page 2
background image

5. Detach the condenser.

-

Remove the retaining bolts.

-

Right-hand side shown, left-hand side similar.

6. Lower the vehicle.

7. Remove the condenser.


Installation
