X-Type (X400) V6-3.0L (2002)
/v6-3.0l/Page-1739001.png)
Fuel Gauge Sender: Electrical Specifications
Sensor Resistance 16 - 160 ohms
With connector(s) disconnected, measure the resistance
between the sensor electrical connectors: FT002 pin 1 and
pin 2/FT003 pin 1 and pin 2.
