X-Type (X400) V6-3.0L (2002)
/v6-3.0l/Page-762001.png)
Ignition Coil: Service and Repair
Ignition Coils-LH
Ignition Coil-On-Plug LH 18.20.44
Removal
1. Disconnect the battery ground cable.
2. Remove the air cleaner.
3. Disconnect the electrical connectors.
4. Remove the ignition coils.
Installation
1. To install, reverse the removal procedure.
-
Tighten to 6 Nm.
