Knock Sensor: Service and Repair

Knock Sensor (KS) 18.30.69

Removal
All vehicles

1. Disconnect the battery ground cable.
2. Disconnect the spring lock coupling.

Vehicles with 2.5L or 3.0L engine

3. Remove the fuel charging wiring harness.

Vehicles with 2.0L engine

4. Drain the cooling system.

5. Disconnect the electrical connector.

-

Detach the harness.

6. Remove the engine trim retaining bracket.

7. Detach the coolant pipe.
