Toe Adjustment-Front|Page 4724 > < Toe Adjustment-Front|Page 4722

X-Type (X400) V6-3.0L (2002)

Page 3
background image

6. NOTE:

Right-hand shown, left-hand similar.

Rotate the tie-rods an equal amount in either a clockwise or a counterclockwise direction to adjust the toe setting.
