X-Type (X400) V6-3.0L (2002)
/v6-3.0l/Page-1220006.png)
9. Detach the wheel knuckle.
1. Remove the lower arm ball joint retaining nut and bolt.
2. Reposition the lower arm.
3. Detach the wheel knuckle.
CAUTION: To prevent damage to the lower arm bushing, make sure the subframe is lowered before detaching the lower arm ball joint.
10. Remove and discard the wheel hub nut.
