6. Install the lifting handles and with assistance, carefully position the windshield glass in the aperture.
-
Align the windshield glass and press firmly into place.
-
Remove the lifting handles.
WARNING: IF THE WINDSHIELD GLASS IS BEING INSTALLED AT 23 °C (73 °F) OR ABOVE MAKE SURE THE VEHICLE IS
NOT DRIVEN FOR AT LEAST 1 HOUR AFTER INSTALLATION.
IF THE WINDSHIELD GLASS IS BEING INSTALLED AT A TEMPERATURE OF 11 °C (52 °F) TO 23 °C (73 °F) MAKE SURE THE
VEHICLE IS NOT DRIVEN FOR AT LEAST 1.5 HOURS AFTER INSTALLATION.
IF THE WINDSHIELD GLASS IS BEING INSTALLED AT A TEMPERATURE OF 5 °C (41 °F) TO 11 °C (52 °F) MAKE SURE THE
VEHICLE IS NOT DRIVEN FOR AT LEAST 2 HOURS AFTER INSTALLATION.
IF THE WINDSHIELD GLASS IS BEING INSTALLED AT A TEMPERATURE BELOW 5 °C (41 °F) USE HEAT AND MAKE SURE
THE WINDSHIELD GLASS ADHEASIVE HAS SET BEFORE THE VEHICLE IS DRIVEN.
CAUTION: When installing the windshield glass, do not strike it in any way as this will crack the glass.
7. Apply suitable protective tape to the top of the windshield glass.
CAUTION: Make sure the windshield glass does not move out of position in the windshield glass aperture.
