Electronic Throttle Actuator: Electrical Diagrams
Throttle Sensors And Controls
Item/Description
1. Mechanical guard position sensor (potentiometer)
2. Pedal demand sensors (potentiometers)
3. Throttle position sensors
4. EMS control module
5. Throttle motor power relay
6. EMS fuse box
7. Throttle motor
