Cherokee 4WD V6-173 2.8L VIN W 2-bbl (1985)

Keyless Entry: Customer Interest
Keyless Entry System - Erratic Operation
AUGUST 1985 000 787
1985 ALLIANCE, ENCORE, EAGLE, CHEROKEE/ WAGONEER MODELS
32E
ELECTRICAL
Attention: Workshop, Parts Department
1985 KEYLESS ENTRY SYSTEM - ERRATIC OPERATION
Some 1985 Alliance, Encore, Eagle, and Cherokee/Wagoneer model vehicles equipped with the optional keyless entry system may experience an
inoperative/intermittent condition when attempting to operate the transmitter.
This erratic condition is the result of poor contacts at the terminal connection.
This condition may be corrected by performing the following procedures.
PROCEDURE
1.
Remove the receiver cover trim plate located above the windshield (between the sun visors).
2.
Disconnect the receiver from the wiring harness terminal connection.
TERMINAL PIN AND CONNECTOR TERMINAL LOCATION
3.
Tighten the terminal connector Insert a terminal pin (A) (fine pointed awl or test lamp probe) into the connector terminal (B) and pry the terminal
pins in an upward direction. Be sure the receiver has good electrical contact.
4.
Reinstall the receiver and receiver cover trim plate.
5.
Press the transmitter and observe the indicator light. A glowing condition means that the transmitter batteries are properly charged.
6.
Aim the transmitter at the receiver to confirm that the receiver is operating properly (ie. that it unlocks and locks the doors).
SRT INFORMATION
OPERATION
NUMBER
TIME
TIC
CO. Receiver Terminals Keyless
0802
0.2
8-731 * * *
Entry - Repair
***Supplier Code: Neimen 523
FILING INFORMATION
File this I.S. Note in the M.R. 171 binder.
