Comanche 4WD L4-150 2.5L VIN H TBI (1986)
Camshaft: Specifications
Camshaft Journal Diameter
No. 1 2.029-2.030 in
No. 2 2.019-2.020 in
No. 3 2.009-2.010 in
No. 4 1.999-2.000 in
Camshaft Bearing Clearance
0.001-0.003 in
