Grand Cherokee 2WD V8-4.7L VIN J (2004)
Seat Belt Buckle Switch: Service and Repair
POWER LUMBAR SWITCH
REMOVAL
1. Disconnect and isolate the battery negative cable.
2. Remove the three screws that secure the outboard seat cushion side shield to the seat cushion frame.
3. Pull the outboard seat cushion side shield away from the seat cushion frame far enough to access the power lumbar switch wire harness connector.
Fig.10 Power Lumbar Switch Remove/Install
4. Disconnect the power seat wire harness connector from the power lumbar switch connector receptacle.
5. Remove the two screws that secure the power lumbar switch to the inside of the outboard seat cushion side shield.
6. Remove the power lumbar switch from the outboard seat cushion side shield.
INSTALLATION
1. Position the power lumbar switch onto the outboard seat cushion side shield.
2. Install and tighten the two screws that secure the power lumbar switch to the inside of the outboard seat cushion side shield. Tighten the screws to
1.5 Nm (14 in. lbs.).
3. Reconnect the power seat wire harness connector to the power lumbar switch connector receptacle.
4. Position the outboard seat cushion side shield onto the seat cushion frame
5. Install and tighten the three screws that secure the outboard seat cushion side shield to the seat cushion frame. Tighten the screws to 1.5 Nm (14
in. lbs.).
6. Reconnect the battery negative cable.
