Grand Cherokee 4WD V8-4.7L (2003)

Page 1
background image

Fluid Pump: Specifications

545RFE

Oil Pump Bolt ................................................................................................................................................................................  28.2 Nm (250 in. lbs.)
Oil Pump Body to Cover Bolt ............................................................................................................................................................  4.5 Nm (40 in. lbs.)
Plate to Oil Pump Body Screw ...........................................................................................................................................................  4.5 Nm (40 in. lbs.)
