Valve Body, A/T|Specifications|Page 4371 > < Transmission Temperature Sensor/Switch, A/T|Locations|Page 4367

Grand Cherokee 4WD V8-4.7L (2003)

Page 1
background image

Valve Body: Specifications

Valve Body to Case Bolt ....................................................................................................................................................................  11.8 Nm (105 in. lbs.)

Valve Body to Transfer Plate Screw ......................................................................................................................................................  5.6 Nm (50 in. lbs.)
