Grand Cherokee 4WD Laredo V8-4.7L (2002)
INSTALLATION
1. Position front propeller shaft under vehicle with rear universal joint over the transfer case yoke.
2. Place front universal joint into the axle pinion yoke.
3. Align mark on the rear link yoke and universal joint to the mark on the transfer case yoke.
4. Loosely install bolts to hold universal joint to transfer case yoke.
5. Align mark on front universal joint to the mark on the axle pinion yoke.
6. Tighten the U-joint strap/clamp bolts at the axle yoke to 19 Nm (14 ft. lbs.).
7. Tighten the universal joint to transfer case bolts to 27 Nm (20 ft. lbs.).
8. Lower the vehicle.
Rear
PROPELLER SHAFT - REAR
REMOVAL
1. Raise and support vehicle on safety stands.
2. Shift the transmission and transfer case if necessary, to their neutral positions.
3. Mark a line across the axle pinion yoke and the propeller shaft yoke for installation reference.
4. Remove the bolts holding the universal joint clamps to the pinion yoke.
5. Slide the slip yoke off of the transmission, or transfer case, output shaft and remove the propeller shaft (Fig. 11).
INSTALLATION
1. Slide the slip yoke on the transmission, or transfer case, output shaft.
2. Align the installation reference marks made on the propeller shaft and pinion yoke.
3. Position universal joint into pinion yoke.
4. Install the universal joint clamp and clamp bolts to the pinion yoke. Tighten bolts to 19 Nm (14 ft. lbs.).
5. Lower the vehicle.
