J-10 Truck L6-258 4.2L VIN C 2-bbl (1984)
Fig. 15 Horn, Multi-Function Buzzer, Power Door Lock & Power Seat Wiring Circuit (Part 2 Of 2). 1983-84
Jeep Workshop Service and Repair Manuals
Accessories and Optional Equipment >
< Diagram Information and Instructions|Page 2078
Page 2
