Liberty 2WD L4-2.4L VIN 1 (2005)
Technical Service Bulletin # 08-039-04
Date: 041208
Audio System - Left Rear Door Speaker Humming Sound
NUMBER: 08-039-04
GROUP: Electrical
DATE: December 08, 2004
THIS BULLETIN IS BEING PROVIDED IN ADVANCE. DO NOT ORDER PARTS OR PERFORM ANY ACTIONS RELATED TO THIS
BULLETIN UNTIL JANUARY 05, 2005.
SUBJECT:
Hum-Like Sound From Left Rear Door Speaker
OVERVIEW:
This bulletin involves installing a twisted pair jumper harness for the left rear speaker.
MODELS:
2005
(KJ)
Liberty / Cherokee
NOTE:
This bulletin applies to vehicles built prior to September 16, 2004 (MDH 0916xx).
SYMPTOM/CONDITION:
A customer may experience a hum-like sound coming from the left rear door speaker. The hum-like sound may be heard when the radio volume is turned
down or during normal sound volume when the radio is tuned to a talk radio station. This condition may be due to electrial inductance (interference) into
the left rear radio harness wires.
DIAGNOSIS:
Turn the radio on and adjust the sound to low volume. If the hum-like condition is present perform the Repair Procedure.
PARTS REQUIRED:
POLICY:
Reimbursable within the provisions of the warranty.
TIME ALLOWANCE:
FAILURE CODE:
Disclaimer:
This bulletin is supplied as technical information only and is not an authorization for repair.
Repair Procedure
1.
Disconnect and isolate the negative battery cable from the battery.
