Liberty 2WD L4-2.4L VIN 1 (2005)
Carpet: Service and Repair
CARPETS AND FLOOR MATS
REMOVAL
Front Carpet
1. Remove front seats.
2. Remove the floor console.
3. Remove the rear seats.
4. Remove the cowl trim panels. Refer to Trim Panel.
5. Remove the B-pillar lower trim. Refer to Trim Panel.
6. Remove the jack assembly.
7. Remove the carpet.
Rear Cargo Carpet
1. Remove the rivets (1) attaching the cargo hooks (3) to the floor.
2. Remove the carpet (2).
INSTALLATION
