Tire Pressure Monitor Receiver / Transponder: Diagrams

Transponder-Tire Pressure-Left Front (Except 2.5L)

Transponder-Tire Pressure-Right Front (Except 2.5L)

Transponder-Tire Pressure-Right Rear (Except 2.5L)
