ENGINE

36

OVERHAUL

OIL FILTER HEAD

Remove

1. Remove and discard oil filter element.
2. Remove 4 bolts securing filter head to cylinder

block.

3. Remove filter head, remove and discard

gasket.

Thermostatic valve - remove

1. Secure oil filter head in a soft-jawed vice with

thermostatic valve vertically upwards.

2. Remove 2 bolts securing thermostatic valve

extension housing to oil filter head.

3. Remove extension housing, remove and

discard ’O’ ring.

4. Withdraw thermostatic valve and spring.

CAUTION: Do not separate valve from
spring.
