Hazard circuit - failure

HAZARD CIRCUIT - FAILURE

Model

Defender North American Specification

Affected vehicles

999307 onwards

Date

1997-03-18

Reference

18/03/97

Bulletin text

Hazard Circuit - Failure

MODEL

Defender North American Specification

DETAIL

After accident damage repairs to the hazard warning system, ie wiring, lamps etc, have been completed, the 30amp E3 fuse (in the under bonnet fuse box) should be checked, together with the hazard unit PRC8876 for full functionality. Under certain conditions the hazard unit may have suffered internal electrical damage without the fuse blowing, if this is the case then the hazard unit should be replaced.

ACTION REQUIRED

In the event of lamp damage, check the 30amp hazard fuse and hazard unit for full functionality.

PARTS INFORMATION

PRC 8876 Hazard unit

PROCEDURE

Refer to the workshop manual section 86, also the vehicle electrical library manual section C547 for location of the hazard unit, and section C570 for the fusebox within the engine compartment.

© Rover Group 1996

18/03/97

86/08/97

AFFECTED VEHICLES

LP LH LJ LD 999307 onwards

WARRANTY

Normal warranty policy and procedures apply

COMP. CODE

7M5V

SRO

86.55.12 Hazard warning unit renew 00.15 hour
