Exhaust mounting rubbers - adrift

EXHAUST MOUNTING RUBBERS - ADRIFT

Model

Defender 90 Tdi Derivatives

Affected vehicles

994360 to 103707

Date

1997-02-21

Reference

21/02/97

Bulletin text

Exhaust Mounting Rubbers - Adrift

MODEL

Defender 90 Tdi Derivatives

DETAIL

A number of instances have come to our attention regarding exhaust hanger rubbers coming adrift from the mounting bracket on Defender 90Tdi Diesel vehicles within the above Vin range. The exhaust hanger rubber bracket, on pass by noise exhaust, ( identified by a single silencer) may be replaced by a longer bracket, which can then be realigned to eliminate further concerns.

ACTION REQUIRED

Upon customer complaint of the exhaust rubbers coming adrift, on 90Tdi fitted with pass by noise exhaust, follow the procedure detailed below.

PARTS INFORMATION

ESR 2087 Longer exhaust hanger bracket

PROCEDURE

Replace the front exhaust hanger bracket for the longer type part number ESR 2087 ( see the illustration opposite). The bracket should be set at its minimum length, the exhaust system will then require both joints to be slackened off and re-aligned. Tighten all fixings to 22-28Nm

© Rover Group 1996

21/02/97

30/01/97/EN

AFFECTED VEHICLES

LP LH LJ LD 994360 to 103707

WARRANTY

Normal warranty policy and procedures will apply

COMP. CODE

2T3B

SRO

30.20.02 Exhaust front mountings renew/adjust 00.10 hour
