Steering damper rattle

STEERING DAMPER RATTLE

Model

Defender

Affected vehicles

From 994360 to 111544

Date

1997-04-30

Reference

30/04/97

Bulletin text

Steering Damper - Rattle

MODEL

Defender

DETAIL

We have received a small number of reports which indicate a rattle emanating from the steering damper, investigations have shown that the damper is not being clamped in the bracket tightly enough due to the thickness of the stem washer.

A new stem washer has been introduced which has a reduced thickness, this will allow the stem to sit into the mounting brackets correctly to achieve the necessary clamping.

ACTION REQUIRED

Upon customer complaint of a rattle emanating from the steering, the new stem washer should be fitted as detailed below.

PARTS INFORMATION

Old part 543819 Stem washer

New part ANR 6942 Stem washer

PROCEDURE

Refer to the workshop manual section 57 steering damper for procedure.

© Rover Group 1996

30/04/97

57/02/97/EN

AFFECTED VEHICLES

LP LH LJ LD From 994360 to 111544

WARRANTY

Normal warranty policy and procedures apply

COMP. CODE

5E1K

SRO

57.55.21 Fit new stem washers 00.20 hour
