300Tdi Defender
CHASSIS AND BODY
5
REPAIR
SILL LOCKING BUTTON - REAR SIDE DOOR
Service repair no - 76.37.30
Remove
1. Remove door trim casing
See Door trim casing
.
2. Peel back sufficient of plastic sheet to reveal
mechanism.
3. Release spring clip securing button to operating
rod and withdraw rod from button.
4. Remove 2 screws securing button to door panel
and remove button.
Refit
5. Secure locking button assembly to door panel
with 2 screws.
6. Fit operating rod to button assembly and secure
with spring clip.
7. Re-seal plastic sheet and fit door trim casing
See Door trim casing .
REMOTE CONTROL LEVER - REAR SIDE DOOR
Service repair no - 76.37.32
Remove
1. Remove door trim casing
See Door trim casing
.
2. Peel-back sufficient of plastic sheet to gain
access to remote lever.
3. Remove spring clip and disconnect control rod
from locking button.
4. Release spring clip and disconnect short locking
button control rod from latch mechanism.
5. Disconnect long remote control rod from latch
assembly.
