300Tdi Defender
CHASSIS AND BODY
31
REPAIR
INTERIOR MIRROR
Service repair no - 76.10.51
Remove
1. Prise interior mirror arm from mounting plate.
2. Remove 3 screws and remove mounting plate
from headlining.
Refit
3. Fit mounting plate to headlining.
4. Locate lower lug of mirror arm in mounting plate
aperture.
5. Press mirror arm firmly to engage spring clip in
mounting plate aperture.
SUN VISORS
Service repair no - 76.10.47
Remove
1. Raise sun visor.
2. Remove 2 screws and collect sun visor.
Refit
3. Position sun visor and secure with 2 screws.
