Discovery II
BRAKES
70-34
REPAIRS
Brake disc - rear
$% 70.12.33
Brake discs must be renewed in pairs, unless
one disc requires changing before 1000 miles
(1500 km) from new.
Remove
1. Raise rear of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
2. Remove road wheel(s).
3. Remove 2 bolts securing brake caliper to rear
hub.
4. Release caliper and tie aside clear of brake
disc.
CAUTION: Do not allow caliper to hang on
brake hose.
5. Remove screw securing disc to drive flange.
6. Remove brake disc from drive flange.
Refit
1. Clean mating faces of drive flange and new
disc.
2. Fit brake disc to drive flange, fit screw and
tighten to 13 Nm (10 lbf.ft).
3. Clean mating faces of caliper and hub.
4. Fit caliper and tighten bolts to 95 Nm (70 lbf.ft).
5. Fit road wheel(s) and tighten nuts to 140 Nm
(103 lbf.ft).
6. Remove stand(s) and lower vehicle.
