Discovery II
STEERING
REPAIRS
57-41
Refit
1. Position PAS pump to auxiliary housing and
locate housing to engine. Fit and tighten
auxiliary housing bolts to 40 Nm (30 lbf.ft).
2. Tighten auxiliary housing nut to 10 Nm (7 lbf.ft).
3. Fit bolts securing PAS pump and tighten to 22
Nm (16 lbf.ft).
4. Position PAS pump pipe bracket, fit and tighten
bolt to 22 Nm (16 lbf.ft).
5. Fit and tighten PAS pump pressure pipe.
6. Fit PAS pump inlet hose and secure with clip.
7. Position jockey pulley and tighten bolt to 50 Nm
(37 lbf.ft).
8. Clean PAS pump pulley mating faces.
9. Position PAS pump pulley, fit bolts and tighten
to 22 Nm (16 lbf.ft).
10. Models with ACE: Clean ACE pump dowels
and dowel holes. Position ACE pump, fit bolts
and tighten to 25 Nm (18 lbf.ft).
11. Models with A/C: Clean A/C compressor
dowels and dowel holes. Position A/C
compressor, fit bolts and tighten to 22 Nm (16
lbf.ft).
12. Position air intake hose and secure with clips.
13. Secure harness to air intake hose with new
cable tie.
14. Fit auxiliary drive belt.
REPAIRS, Belt - auxiliary drive..
15. Bleed PAS system.
