Driver closure plate fixing stud omitted

DRIVER CLOSURE PLATE FIXING STUD OMITTED

Model

Discovery all Derivatives Discovery all Derivatives

Affected vehicles

from 164856 to 166256 from 502286 to 502686

Date

1995-07-18

Reference

18/07/95

Bulletin text

Driver Closure Plate Fixing Stud Omitted

MODEL

Discovery all Derivatives Discovery all Derivatives

DETAIL

A small number of vehicles within the above Vin range may have been despatched from Land Rover, with one of the foot pedal closure panel fixing studs omitted.

Note: As from June 1995 Discovery is produced on two production lines, therefore you will find VIN numbers that commence with both ‘5’ and ‘1’.

ACTION REQUIRED

A visual inspection will be required on vehicles within the above VIN range for the absence of any of the three closure panel fixing studs.

PARTS INFORMATION

BTR 9437 Fixing stud

PROCEDURE

Check the foot pedal closure panel (as shown in the illustration opposite) for the fixing studs, if any have been omitted, fit new studs.

18/07/95

76/32/95/EN

AFFECTED VEHICLES

LP LH LJ from 164856 to 166256 LJ from 502286 to 502686

WARRANTY

Normal warranty policy and procedures apply

COMP. CODE

8C3G

SRO

76.46.89/29 Check and fit as required 00.05 hour
