Washer pump link lead

WASHER PUMP LINK LEAD

Model

Range Rover Classic Discovery

Affected vehicles

Upto 647645 Upto 081991

Date

1995-04-19

Reference

19/04/95

Bulletin text

Washer Pump Link Lead

MODEL

Range Rover Classic Discovery

DETAIL

A new front and rear screen washer pump was introduced onto Range Rover Classic and Discovery from the above Vin numbers. The new part also supersedes similar part fitted prior to LH 647645 and LJ 081991 and therefore requires the fitment of a special conversion lead to enable the new part to fitted to older vehicles.

A link lead has been developed and is available from Unipart. (see parts information below), the new link lead connects between the main harness, and the 2 pin connector on the washer pump body.

ACTION REQUIRED

For information only: If a washer pump is replaced on vehicles prior to the vin numbers identified above, the updated pump and link lead should be used.

PARTS INFORMATION

AMR 3849 Link Lead

Range Rover Front Pump STC 1454 Rear Pump STC 1453

Discovery Front Pump AMR 3660 Rear Pump STC 1946

PROCEDURE

Refer to the workshop manual section 84 washer pump - windscreen or tailgate.

1. Drain washer bottle 2. Replace washer pump 3. Fit link lead AMR 3849 between the main harness and the washer pump. 4. Re-fill washer bottle

19/04/95

84/03/95/EN

AFFECTED VEHICLES

LP LH Upto 647645 LJ Upto 081991 LD

WARRANTY

Normal warranty policy and procedure apply

COMP. CODE

Not Applicable

84.10.21 Replace washer pump and fit link lead 00.20
