Special service tools

SPECIAL SERVICE TOOLS

Model

Range Rover Classic Discovery

Affected vehicles

647645 Onwards 081991 Onwards

Date

1995-04-05

Reference

05/04/95

Bulletin text

Special Service Tools

MODEL

Range Rover Classic Discovery

DETAIL

Following changes in the manufacturing process it has become necessary to introduce two new special tools.

Range Rover Classic and Discovery Remover-Differential pinion flange centralising peg LRT-51-008, Uk list price = £54.40 plus taxes and carriage.

This tool is a mandatory holding requirement for all dealers

NOTE: This bulletin replaces issue 1 numbered A/D856. The bulletin number on issue 1 is incorrect. Please remove the front bulletin sheet and replace with issue 2. Retain the order form attachment supplied with issue 1.

ACTION REQUIRED

Special Tool. Uk dealer network - no action required - tools will be despatched direct from V.L. Churchill. Rest of World markets - please complete the attached order form and return your order direct to V.L. Churchill. Prior to order please see Technical Information Bulletin NRR/07/01/95/EN

PARTS INFORMATION

Remover differential pinion flange centralising peg LRT-51-008

PROCEDURE

Refer to the workshop manual Publications LJBWMEN95 Discovery LHBWMEN95 Range Rover Classic

Section 51-Overall, page 1, Remove pinion rear axle differential only.

The information contained in item 7 relating to the special service tools has changed, service tools MS284 and LST 284-1 are no longer required, and have been replaced by service tool LST-51-008, please amend your workshop manuals accordingly.

Issue 2 05/04/95

07/02/95/EN

AFFECTED VEHICLES

LP LH 647645 Onwards LJ 081991 Onwards LD

WARRANTY

Not applicable

COMP. CODE

Not applicable

SRO

Not applicable
