300Tdi Discovery
FRONT SUSPENSION
3
REPAIR
7. Withdraw lower seating washer, rubber bush and
cupwasher.
8. Remove fixings, shock absorber to mounting
bracket.
9. Withdraw mounting bracket.
10. Lift off top seating washer, rubber bush and
cupwasher.
Refit
11. Reverse removal procedure. 1 to 10.
FRONT ROAD SPRING
Service repair no - 60.20.11.
Remove
1. Remove front shock absorber.
See Front
Shock Absorber
CAUTION: Avoid over stretching brake
hoses. If necessary loosen hose connector
locknuts to allow hoses to follow axle.
2. Lower axle sufficient to free road spring.
3. Withdraw road spring.
4. Withdraw shock absorber bracket securing ring.
Refit
5. Fit shock absorber bracket retaining ring. Retain
in position with a nut.
6. Reverse 2 and 3.
7. Remove nut retaining securing ring.
8. Fit front shock absorber.
