300Tdi Discovery
86
ELECTRICAL
44
REPAIR
BONNET SWITCH
Service repair no - 86.55.89
Remove
1. Remove 2 bolts securing sounder, move
sounder aside.
2. Locate and disconnect bonnet switch multiplug.
3. Release and remove switch.
Refit
4. Reverse removal procedure.
ULTRASONIC SENSOR
Service repair no - 86.77.32
Remove
1. Release sensor from switch panel.
2. Disconnect multiplug and remove sensor.
Refit
3. Reverse removal procedure.
ANTI-THEFT ALARM INDICATOR LIGHT (96
MODELS)
Service repair no - 86.45.61
See Instrument illumination and warning light
bulbs
ENGINE IMMOBILISATION WARNING LIGHT (96
MODELS)
Service repair no - 86.45.61
See Instrument illumination and warning light
bulbs
