L322 Range Rover System Description and Operation
AIR CONDITIONING
DESCRIPTION AND OPERATION
82-31
FBH Remote Handset
1 Antenna
2 Off button
3 On button
4 LED
The FBH remote handset allows parked heating to be remotely controlled up to a minimum of 100 m (328 ft) from the
vehicle. On and off buttons activate and de-activate parked heating, a red LED illuminates to indicate when parked
heating is active and when the on/off signals have been received by the vehicle. The FBH remote handset is powered
by two serviceable 1.5 V batteries located under a cover on the rear of the handset.
FBH Remote Handset Battery Replacement
M82 0835
4
1
2
3
M82 0836
