L322 Range Rover System Description and Operation
AUTOMATIC TRANSMISSION – ZF 5HP24
44-2-42 DESCRIPTION AND OPERATION
Additionally, the display also shows a low range symbol when low range is selected on. The low range symbol is
illuminated in an amber colour when active. When the transfer box is changing from low to high range, the low range
symbol flashes until the range change is complete.
Message Centre Display
The message centre is located below the speedometer and the tachometer at the bottom of the instrument pack. The
message centre is a Liquid Crystal Display (LCD) to relay vehicle status information to the driver. The message centre
can display the following transmission related messages:
l
SPORT MODE
l
MANUAL MODE
l
SELECT NEUTRAL
l
TRANSMISS'N OVERHEAT
l
TRANSMISS'N FAILSAFE PROG
l
LOW RANGE
l
HIGH RANGE
l
SLOW DOWN.
