L322 Range Rover System Description and Operation
AUTOMATIC TRANSMISSION – ZF 5HP24
DESCRIPTION AND OPERATION
44-2-5
1 Torque converter lock-up clutch
2 Torque converter
3 Fluid pump
4 Clutch A
5 Clutch B
6 Clutch C
7 Clutch D
8 Clutch E
9 Planetary gearset 1
10 Planetary gearset 2
11 Planetary gearset 3
12 Clutch F
13 Freewheel clutch – 1st Gear
14 Park lock pawl
15 Speed sensor target wheel
16 Output shaft speed sensor
17 Valve body channel plate
18 Pressure regulator and shift control solenoids
19 Upper valve body
20 Rear lower valve body
21 Fluid filter
22 Forward lower valve body
23 Turbine speed sensor
24 Fluid pan
25 Main casing
26 Fluid pressure control valve
27 Bell housing
28 Input shaft
