CHARGING AND STARTING

86-1-6

DESCRIPTION AND OPERATION

Td6 Starter Motor

The starter motor is located on the rear LH side of the engine block. The motor is secured to the block and protrudes
through an aperture to drive the flywheel via a ring gear.
