Range Rover TV Operation
ENTERTAINMENT AND INFORMATION SYSTEMS
DESCRIPTION AND OPERATION 86-8-39
To adjust the volume of a traffic report, turn the volume control to the desired level whilst a traffic report is being
broadcast. This volume is then retained for traffic reports even when the volume has been changed for other audio
sources.
Cassette Operation
To insert a cassette the eject button should be pressed, once pressed the front display panel will drop down to reveal
the cassette slot. Once the tape is inserted it will begin to play automatically. If it is required to change from radio to
cassette operation the mode change button should be pressed. The screen displays the Tape 1 or Tape 2, depending
on which side of the tape was being played the last time cassette operation was accessed.
To fast forward or rewind the tape press the required direction key twice. Pressing one of the direction keys will cancel
this operation and return to play mode.
To operate the track search function press the direction key once in the desired direction. The tape will advance until
it reaches the next track where it will then commence playing. It should be noted that this function will only operate if
there is at least a 4 second gap between tracks.
CD Autochanger Operation
The CD autochanger is located in the passenger compartment glove box. The autochanger is capable of holding 6
CDs which are loaded into a cartridge.
The CD player function is accessed by pressing the mode button until the display shows the CD screen. The screen
will display the CD number and track number being played. The CD autochanger has several functions:
l
Track search
l
Random play
l
Fast forward/reverse
l
Track scan.
Track search is achieved by pressing the direction arrow key as often as required to reach the desired track.
Random play plays all the track on all the CDs in a random order. This is selected by pressing the select key until the
appropriate screen is visible, turning the rotary controller to highlight the Random button and selecting.
Fast forward/reverse is selected by pressing and holding the direction key in the desired direction or by highlighting
the double arrow button in the display using the rotary controller and selecting by pressing the rotary controller.
The track scan function is accessed by turning the rotary controller until 'Track scan' button is highlighted and pressing
the rotary controller to select. Press the track select key starts the search. The player will play the first 10 seconds of
each track until it is stopped at the required track by pressing the track select key.
Television Operation
The Television image is displayed only up to a speed of 3 km/h (approx. 2 mph), the accompanying television audio
can be heard while the car is being driven. Television operation is selected from the menu screen. Once selected the
screen displays the television programme last used or the last used selection and the following menu screen:
l
Programme
l
Search
l
Autostore
l
Set
l
Display
l
Teletext.
Programme
Selecting programme from the menu allows the user to scroll through the available stored memory locations.
Search
Selecting the search option allows the user to search for a television station and to store that station to a memory
location. This is achieved by selecting the search option and scrolling through the channels with the rotary controller
and pressing the rotary controller to select. This will then bring up the location store option, turn the rotary controller
until the required location is shown and press the rotary controller once to store the station at that memory location.
