L322 Range Rover System Description and Operation
INSTRUMENTS
88-20
DESCRIPTION AND OPERATION
MFD Programming
MFD 'REMOTE CONTROL' Screen
1 Ensure that the ignition switch is in position I (AUX) or position II.
2 Press and hold the column stalk 'i' button for 3 seconds. 'REMOTE CONTROL' screen is displayed in the MFD
with all computer functions shown. Simultaneously, 'PROG' is displayed in the message centre.
3 To set the sequence, first deselect all functions using the RH control on the MFD panel. Select the function and
press the RH control to deselect that function. When deselected, the selection text will change colour.
4 Using the RH control, navigate to the first required computer function and press the RH control to select. When
selected, the selection text will change colour.
5 Continue selecting functions in the required order as required. If no functions are selected, there will be no
response from the 'i' button when pressed. All or just one function can be selected for display.
6 When desired selections are made, navigate to the 'memorise' function and press the RH control. The selected
functions are stored in their selected order in the instrument pack RAM. The instrument message centre then
displays the first selected function.
MID Programming
MID 'PROG 1' Display
1 Ensure that the ignition switch is in position I (AUX) or position II.
2 Press and hold the 'i' button for 3 seconds. 'PROG 1' appears in the MID with all computer functions assigned
to the keys.
M88 0351
Arrival time
Arrival time
Range
Distance
Limit
Clock
Date
Average speed
Average speed
Consump 2
Consump 2
Consump 1
Consump 1
Timer
Timer 2
Timer 2
Timer 1
Timer 1
memorise
REMOTE CONTROL
REMOTE CONTROL
TMC
30/07/2001
14:10
M88 0352
*
PROG 1
RANGE
SPEED
LIMIT
DIST ARR
CONSUM1
SET
