L322 Range Rover System Description and Operation
INSTRUMENTS
DESCRIPTION AND OPERATION
88-5
1 Fuse - Battery permanent supply
2 Diagnostic socket
3 Anti-lock Brake System (ABS) ECU
4 Hand brake switch
5 Supplementary Restraint System (SRS) DCU
6 Brake fluid level switch
7 Engine coolant level sensor
8 Washer fluid level sensor
9 Light Check Module (LCM)
10 Instrument pack
11 Engine Control Module (ECM)
12 Oil pressure sensor
13 Ambient air temperature sensor
14 Fuel tank level sensor LH
15 Fuel tank level sensor RH
16 Engine Coolant Temperature (ECT) sensor
17 Sounder
18 I Bus interface
19 K Bus interface
20 CAN interface
21 Brake pad wear sensor - Rear RH
22 Brake pad wear sensor - Front LH
23 Body Control Unit (BCU)
24 LH Column stalk switch
25 Fuse - ignition feed
26 Ignition switch
