LIGHTING

86-2-18 DESCRIPTION AND OPERATION

Xenon Headlamp Construction

1 Reflector
2 Shutter controller
3 Shutter
4 Adapter ring
5 Spring clip

6 Lens
7 Foreign touring beam adjustment lever
8 Xenon bulb
9 Bulb retention ring

4

3

2

M86 5875

5

45,88

1

6

7

8

9
