L322 Range Rover System Description and Operation
LIGHTING
DESCRIPTION AND OPERATION
86-2-7
1 LH rear tail lamp
2 LH rear direction indicator lamp
3 RH rear direction indicator lamp
4 RH rear tail lamp
5 Light control switch
6 LH rear fog lamp
7 RH rear fog lamp
8 LH brake lamp
9 Centre High Mounted Stop Lamp (CHMSL)
10 RH brake lamp
11 Navigation ECU
12 Rear wiper motor and control module assembly
13 LH front direction indicator lamp
14 LH front side lamp
15 RH front side lamp
16 RH front direction indicator lamp
17 RH reverse lamp
18 LH reverse lamp
19 Trailer module
20 Light Check Module (LCM)
21 RH rear side marker lamp (NAS only)
22 LH rear side marker lamp (NAS only)
23 LH front side marker lamp (NAS only)
24 RH front side marker lamp (NAS only)
