L322 Range Rover System Description and Operation
LIGHTING
DESCRIPTION AND OPERATION 86-2-35
1 Fuse – Permanent battery supply (5A)
2 Fuse – Ignition supply (30A)
3 Front interior lamp assembly
4 Rear interior lamp assembly
5 Glove box lamp and switch
6 Sill lamp LH (fascia mounted)
7 Sill lamp RH (fascia mounted)
8 RH door mirror approach lamp
9 LH door mirror approach lamp
10 LH rear door puddle lamp
11 RH rear door puddle lamp
12 Passenger door puddle lamp
13 Driver's door puddle lamp
14 Fuse – vanity mirror illumination
15 RH vanity mirror illumination lamps
16 LH vanity mirror illumination lamps
17 LH footwell lamp (under fascia mounted)
18 RH footwell lamp (under fascia mounted)
19 LH upper tail door lamp
20 RH upper tail door lamp
21 Load space illumination lamp
22 Upper tail door latch motor switch
23 Body Control Unit (BCU)
24 Interior lamp relay
25 Fuse – Ignition switched supply (5A)
26 Ignition switch
