L322 Range Rover System Description and Operation
SEATS
DESCRIPTION AND OPERATION
76-5-3
Electric Seats
The electric seats are adjusted in the following axes by switches fitted in the seat side trim panel:
l
Forward/back adjustment
l
Seat cushion height
l
Seat cushion angle – driver's seat only
l
Backrest angle
l
Lumbar support – horizontal and vertical.
The seat has the following manual adjustments:
l
Headrest angle
l
Headrest height.
Contour Seats
Contour Seat – Adjustment
1 Memory store and preset switches
2 Upper backrest adjustment
3 Seat backrest adjustment
4 Forward/backward/cushion height/cushion
angle adjustment
5 Lumbar support adjustment
In addition to the electric seat adjustments the Contour seat has the following additional functions:
l
Electrical adjustment of the seatback head adjustment
l
Seat angle adjustment – driver and passenger seats
l
Seat heating.
Memory Function
This function, available as optional equipment, has three memory positions stored for the seats and exterior mirrors.
The switch for this function is located on driver's seat outer side trim panel.
Controlled by the Body Control Unit, the memory recall functions are:
l
Forward/backward adjustment
l
Seat height
l
Seat angle – driver's side only
l
Backrest angle
l
External mirror adjustment – left and right
l
Steering column forward/backward adjustment.
M76 4561
"
#
!
