L322 Range Rover System Description and Operation
SECURITY
DESCRIPTION AND OPERATION
86-5-7
RF Remote Handset
1 Tail door open button
2 Lock button
3 Unlock button
4 LED
The remote handset functions as follows:
l
One press of the lock button for superlocking
l
Two presses of the lock button for no volumetric protection
l
Press and hold the tail door switch for panic mode.
The power supply in the remote handset is provided by a single button cell battery on RF systems and two button cell
batteries on infrared systems. When the batteries need replacing the message 'KEY BATTERY LOW' will be
displayed in the message centre. When the batteries are replaced, the old ones should be removed and the new ones
installed within 1 minute or stored data will be lost and the remote handset will need to be re-initialised.
M86 5943
3
2
1
4
