background image

MAINTENANCE

PROCEDURES

10-17

Brake  hose, brake pipes, fuel pipes,
hydraulic pipes and unions/electrical
harnesses

Check - general

1. Check brake servo hose for cracks, leaks and

chafing.

2. Check brake pipes and unions for chafing,

leaks and corrosion and  that all pipes and
hoses are correctly routed and secure.

3. Check electrical harnesses for chafing and

damage.

Check – Td6/V8 engine fuel pipes

1. Check visible fuel pipes and unions for chafing,

leaks and corrosion and that all pipes and
hoses are correctly routed and secure.

Power steering and suspension

1. Check for fluid leaks from power steering and

suspension systems.

2. Check hydraulic pipes and unions for chafing,

leaks and corrosion and that all pipes and
hoses are correctly routed and secure.

Engine, automatic gearbox, transfer box,
front and rear and differentials

Check

1. Check for oil leaks from engine, automatic

gearbox , transfer box  and front and rear
differentials; pay particular attention to areas
around oil  seals.
